Parts catalog 7-59
5061
Assembly 31: HCIT
Asm-
Index
Part
number
Units/
option
Units/
FRU
Description
31–1 40X2137 1 1 Paper size sensor box assembly
2 40X2111 1 1 Flag, paper size F
3 40X2112 1 1 Flag, paper size C
4 40X2110 1 1 Flag, paper size R
5 40X2113 3 1 Spring, paper size flag
6 40X2108 10 1 Sensor, photo interrupter
7 40X2103 1 1 Paper size sensors cable
8 40X2095 1 1 System control board
9 Screw type 312/322/412/423, parts packet, 40X1691
10 40X2096 1 1 LVPS
11 40X2105 1 1 Elevator motor assembly
12 40X2097 1 1 AC power outlet
13 40X2098 1 1 AC power inlet
14 40X2091 1 1 AC power cord jumper
15 40X2115 1 1 Paper tray guide
16 40X2134 1 1 Elevator lift belt
17 40X2136 1 1 Elevator lift
18 40X2139 3 1 Ring 7, elevator lift gear/elevator lift
19 40X2135 1 1 Elevator lift gear
20 40X2114 2 1 Paper tray arms
21 40X2116 1 1 Feed unit, complete assembly
22 40X2118 2 1 Bushing
23 40X2124 1 1 Front feed unit spring
24 40X2125 1 1 Rear feed unit spring
25 40X2138 1 1 Feed cover
26 40X2131 2 1 Separation/torque roller
27 40X2120 2 1 Feed cam
28 E-clips, parts packet, 40X2122
29 40X2119 2 2 Feed roller
30 40X2121 2 1 Feed unit spring
31 40X2123 1 1 060 bushing
32 40X2133 2 1 Emitter timing wheel
33 40X2126 2 2 Plastic 5W clip
34 40X2117 2 1 Special optical sensors
35 40X2127 1 1 Level sensor flag
36 40X2129 1 1 Extension spring
37 40X2128 1 1 Near empty sensor flag
NS 40X2090 1 1 HCIT option
