Parts catalog 7-61
5061
Assembly 31.1: HCIT
Asm-
Index
Part
number
Units/
option
Units/
FRU
Description
31.1–1 40X2145 1 1 Rear cover
2 40X2143 1 1 Right side cover
3 40X2092 2 1 Caster, movable
4 16 16 Screw type 312/322/412/423, parts packet, 40X1691
5 40X2094 4 1 F adjuster
6 40X2141 1 1 Front cover
7 40X2142 1 1 Cover, main CA
8 40X2093 2 1 Caster, fixed
9 40X2144 1 1 Left side cover
10 40X2146 1 1 Upper left side jam cover
11 40X2100 1 1 Locating pin, options front right
12 40X2099 1 1 Locating pin, options rear left
13 40X2106 1 1 Options autoconnect cable assembly
14 40X2109 1 1 Options cable mounting plate
NS 40X2101 1 1 Feed unit special sensors cable
NS 40X2102 1 1 Feed unit sensors cable
NS 40X2104 1 1 Elevator motor cable
NS 40X2107 1 1 Magnetic latch
NS 40X2130 1 1 Tray present lever
NS 40X2132 9 1 Cable clamp
NS 40X2140 1 1 Stabilizer kit with mounting screws
