215676 281 Revision A
3. Shut down the engine, and remove the key from
the ignition.
Figure 4.272: Safety Prop
4. To engage the safety props on the lift cylinders:
a. Pull lever (A) and rotate it toward the header to lower
safety prop (B) onto the cylinder.
b. Repeat the previous step for the opposite lift cylinder.
Figure 4.273: Header Boots
5. Remove hairpin (B) from clevis pin (A) and remove the
clevis pin from header boot (C) on both sides of the header.
OPERATION
