215676 395 Revision A
Figure 5.135: Headlight Assembly
2. Detach the wiring harness connector from the headlight
assembly. Remove rubber insulator boot (A).
Figure 5.136: Headlight Assembly
3. Pinch wire retainer (A) and lift it away from the hooks.
4. Remove bulb (B) from the headlight body.
MAINTENANCE AND SERVICING
