215676 492 Revision A
Codes
CDM Display Description
E28 E128 TILT RETRACT
Header tilt retract solenoid P54, fault detected
E29 E129 TILT EXTEND
Header tilt extend solenoid P53, P54, fault detected
E30 E130 4 WAY VALVE P62
4-way valve solenoid P62 fault detected
E31 E131 BYPASS VALVE P52
Bypass valve solenoid P52 fault detected
E32 E132
HEADER UP/DOWN P57
Header up/down solenoid P57, fault detected
E33 E133 SCREEN CLEANERS
Screen cleaner output fault detected
E34 E134 RIGHT STOP LAMP
Right stop lamp output fault detected
E35 E135 LEFT STOP LAMP
Left stop lamp output fault detected
75
E36 E136 RIGHT TURN LAMP
Right turn lamp output fault detected
76
E37 E137
LEFT TURN LAMP
Left turn lamp output fault detected
E38 E138 MAIN DRIVE
Main header drive solenoid P71 fault detected
E39 E139 LOW RANGE P61
Low range solenoid P61 fault detected
E40 E140 HIGH RANGE P60
High range solenoid P60 fault detected
E41 E141 REEL AFT
Reel aft solenoid P55, P59, fault detected
E42 E142 REEL FORE
Reel fore solenoid P55, P59, fault detected
E43 E143
REEL UP/DOWN P58
Reel up/down solenoid P58, P52, P62 fault detected
E44
E144
FLOAT RHS P64
Right float solenoid P64, fault detected
E45 E145
FLOAT LHS P63
Left float solenoid P63, fault detected
E46 SENSOR VOLTS HIGH
WCM’s 9V Sensor voltage output high (wire 5)
E47 SENSOR VOLTS LOW
WCM’s 9V Sensor voltage output low (wire 5)
E48 WCM OVER TEMP
E49 the temp limits are set to -10C and +85C representing the
board temp read by the chip inside the WCM module; this is to
protect the module when operating at extreme temp; the WCM
outputs will stop working (they stay off) when the board temp is
below -20C or above 120C; the high temp may indicate a strong/
massive short circuit in the cabling on the WCM outputs
E49 WCM LOW TEMP
WCM low temp fault
E50 BATT+ OUT OF RANGE
System voltage above 15.5 VDC
E51 E151
DISK DRIVE PWM P68
Disk header drive solenoid P68 fault detected
E52
——
E53
——
E54
——
E55
DISK SPD OVERLOAD
Low disk speed detected < setpoint
Error codes E56 to E63 not allocated
E64 HEADER OIL PRESSURE
Header drive charge pressure low (Switch MD #112848 on return
manifold)
E65 KNIFE OVERLOAD
Low knife speed detected < setpoint
E66 ##.# LOW VOLTS
Low system voltage <11.5 VDC
E67 TRANS OIL PRESSURE
Supercharge pressure low (switch MD #139775)
E68 HYDRAULIC OIL HOT
Oil tank temp >110°C (230°F)
E69 ENGINE AIR FILTER
Engine air filter plugged
REFERENCE
75. If road light kit is not installed, CDM will display E135 LEFT STOP LAMP as a malfunction in CAB-FORWARD mode.
76. If road light kit is not installed, CDM will display E134 RIGHT STOP LAMP as a malfunction in CAB-FORWARD mode.
