215676 493 Revision A
Codes
CDM Display Description
E70 HYDRAULIC FILTER
Hydraulic filter pressure too high (MD #139722)
E71 LOW HYDRAULIC OIL
Low hydraulic oil level sensor tripped (MD #138473)
E72 ##.# HIGH VOLTS
System voltage above 15.5 VDC
Error codes E73 to E100 not allocated
E101 SPI ERROR
Indicates that the communication between the two micros inside
the WCM module is not working properly; could be resolved by
reprogramming the WCM
E102 CAN ERROR
E102 is detected by the WCM module so the issue is related to
the CANBUS signals on the WCM end; it may happen when the
CDM sees the engine ECU but not the WCM (not hooked up or
experiencing power or CANBUS problems; may also happen if the
CDM connector P38, pin 8 signal is malfunctioning or the wire
between the CDM connector P38, pin 8 and WCM connector P36,
pin 30 is not making a proper connection). The wire at the CDM is
CB60 and at the WCM CH60
E103 EEPROM READ ERROR
Internal errors specific to the WCM; try reprogramming
the module
E104 EEPROM WRITE ERROR
Internal errors specific to the WCM; try reprogramming
the module
E105 TEMP SENSOR ERROR
Internal errors specific to the WCM; try reprogramming
the module
REFERENCE
