CONTROL SYSTEM
U–35
U
BLOWER MOTOR REMOVAL/INSTALLATION
A6E854061140W01
1. Disconnect the negative battery cable.
2. Remove in the order indicated in the table.
3. Install in the reverse order of removal.
End Of Sie
BLOWER MOTOR INSPECTION
A6E854061140W02
1. Connect battery positive voltage to terminal A and ground to terminal B of the blower motor and verify its
operation.
• If not as specified, replace the blower motor.
End Of Sie
RESISTOR REMOVAL/INSTALLATION
A6E854061215W01
1. Disconnect the negative battery cable.
2. Remove the glove compartment.
3. Remove the car navigation unit. (See T–98 CAR-NAVIGATION UNIT REMOVAL/INSTALLATION.)
4. Remove in the order indicated in the table.
5. Install in the reverse order of removal.
End Of Sie
1 Blower motor connector
2Blower motor
A6E8540W060
A6E8540W010
1 Resistor connector
2Resistor
A6E8540W011
To Next Page
