21 A/D CONVERSION INSTRUCTIONS
21.3 Restoring the User Range Setting Values
• For R60DA4, R60DAH4
Operand: (s)
Device Item Description Setting range Set by
+0 System area 
+1 Completion status The instruction completion status is stored.
• 0: Completed successfully
• Other than 0: Completed with an error (error code)
 System
+2 Save data type setting Used to store the set value that was set for Save data type
setting (s)+2 in the G(P).OGLOAD instruction.
• 0: User range setting (voltage specification)
• 1: User range setting (current specification)
0000H to 000FH System
+3 System area 
+4 CH1 Factory default setting offset value System
+5 CH1 Factory default setting gain value System
+6 CH2 Factory default setting offset value System
+7 CH2 Factory default setting gain value System
+8 CH3 Factory default setting offset value System
+9 CH3 Factory default setting gain value System
+10 CH4 Factory default setting offset value System
+11 CH4 Factory default setting gain value System
+12 CH1 User range setting offset value System
+13 CH1 User range setting gain value System
+14 CH2 User range setting offset value System
+15 CH2 User range setting gain value System
+16 CH3 User range setting offset value System
+17 CH3 User range setting gain value System
+18 CH4 User range setting offset value System
+19 CH4 User range setting gain value System
b15 b3 b2 b1 b0
0
…
CH4 CH3 CH2 CH1
