5. ETHERNET CONNECTION
5.4 PLC Side Setting
5 - 47
5
ETHERNET CONNECTION
[Controller Setting] and [Ethernet] of GT
Designer3
[Controller Setting] and [Ethernet] of GT Designer3
For [Controller Setting] and [Ethernet] of GT
Designer3, refer to the following.
5.3.1 Setting communication interface
(Communication settings)
(1) Controller setting
*1 Set the GOT network No. according to the third octet
(network No.) of the Ethernet adapter module IP address.
(2) GOT Ethernet setting
(3) Ethernet setting
*1 Set according to the third octet (network No.) of the Ethernet
adapter module IP address.
*2 Set according to the fourth octet (PC No.) of the Ethernet
adapter module IP address.
*3 Set according to the Ethernet adapter module IP address.
(4) Routing parameter setting
*1 Set the same value as the Ethernet adapter module network
No.
*2 Set according to the third octet (network No.) of the Ethernet
adapter module IP address.
*3 Set according to the fourth octet (PC No.) of the Ethernet
adapter module IP address.
Item Set value (Use default value)
GOT Net No.
3
*1
GOT Station 1
GOT Ethernet Setting 192.168.3.18
GOT Communication Port No. 5001
Retry 3 times
Startup Time 3 sec
Timeout Time 3 sec
Delay Time 0ms
Item Set value (Use default value)
GOT IP Address 192.168.3.18
Subnet Mask 255.255.255.0
Default Gateway 0.0.0.0
Peripheral Communication Port
No.
5015
Transparent Port No. 5014
Item Set value
Ethernet Setting
No.1
Host *
N/W No.
3
*1
PC No.
30
*2
Type NZ2GF-ETB
IP address
192.168.3.30
*3
Port No. 5001(fixed)
Communication UDP(fixed)
Item Set value
Transfer Network No.
1
*1
Relay Network No.
3
*2
Relay Station No.
30
*3
To Next Page
