Mitsubishi GOT2000 Series Connection Manual

6. DIRECT CONNECTION TO CPU
6.2 System Configuration
6 - 11
6
DIRECT CONNECTION TO CPU
 When connecting to FX1S, FX1N, FX2N, FX1NC, FX2NC (RS-422 connection)
*1 The function expansion board to be used differs according to the type of the FXCPU to be connected.
Use the applicable function expansion board shown in the following table.
*2 For details of the GOT multi-drop connection, refer to the following.
18. GOT MULTI-DROP CONNECTION
*3 When using function expansion boards or function adapters, confirm the communication settings.
6.5 Precautions Connection to FXCPU (2)When connecting with function extension board or communication special
adapter
PLC Connection cable GOT
Number of
connectable
equipment
Model
name
Function
expansion
board
*1*3
Function
adapter
*3
Communi
cation
type
Cable model
Max.
distance
Option device Model
FX
1S
FX1N
FX2N
FX1NC
FX2NC
--RS-422
GT01-C10R4-8P(1m)
GT01-C30R4-8P(3m)
GT01-C100R4-8P(10m)
GT01-C200R4-8P(20m)
GT01-C300R4-8P(30m)
30m
- (Built into GOT)
1 GOT for 1
PLC built-in
port
GT15-RS4-9S
GT01-RS4-M
*2
-
FX
1S
FX1N
FX2N
FX1N-422-BD
FX2N-422-BD
-RS-422
GT01-C10R4-8P(1m)
GT01-C30R4-8P(3m)
GT01-C100R4-8P(10m)
GT01-C200R4-8P(20m)
GT01-C300R4-8P(30m)
30m
- (Built into GOT)
1 GOT for 1
function
expansion
board
GT15-RS4-9S
GT01-RS4-M
*2
-
Item
Function expansion board to be used
When connecting to FX1N or FX1S Series When connecting to FX Series
RS-422 communication FX
1N-422-BD FX2N-422-BD

Mitsubishi GOT2000 Series Specifications

General

Power Supply	24VDC
Software	GT Works3
Processor	RISC CPU
Interface	Ethernet, USB, RS-232, RS-422/485
Operating Temperature	0°C to 50°C
Display Type	TFT LCD
Storage Temperature	-20°C to 60°C
Humidity	10% to 90% (non-condensing)
Shock Resistance	147 m/s² (15G), 11ms duration
Touch Panel	Analog Resistive
