6. DIRECT CONNECTION TO CPU
6.2 System Configuration
 When connecting to FX1S, FX1N, FX2N, FX1NC, FX2NC (RS-232 connection)
PLC Connection cable GOT
Number of
connectable
equipment
*3
Model
name
Function
expansion
board
*1*3
Function
adapter
*3
Communi
cation
type
Cable model
Connection diagram
number
Max.
distance
Option device Model
FX1S
FX1N
FX2N
FX1N-232-BD
FX
2N-232-BD
-RS-232
GT01-C30R2-9S(3m)
or
RS232 connection
diagram 1)
15m
- (Built into GOT)
1 GOT for 1
function
expansion board
GT15-RS2-9P
GT01-RS4-M
*2
-
FX
1N-CNV-BD
FX
2N-CNV-BD
FX
2NC
-232ADP
RS-232
GT01-C30R2-9S(3m)
or
RS232 connection
diagram 1)
15m
- (Built into GOT)
1 GOT for 1 PLC
built-in port
GT15-RS2-9P
GT01-RS4-M
*2
-
FX
0N
-232ADP
RS-232
GT01-C30R2-25P(3m)
or
RS232 connection
diagram 2)
15m
- (Built into GOT)
GT15-RS2-9P
GT01-RS4-M
*2
-
FX1NC
FX2NC
-
FX2NC
-232ADP
RS-232
GT01-C30R2-9S(3m)
or
RS232 connection
diagram 1)
15m
- (Built into GOT)
GT15-RS2-9P
GT01-RS4-M
*2
-
FX
0N
-232ADP
RS-232
GT01-C30R2-25P(3m)
or
RS232 connection
diagram 2)
15m
- (Built into GOT)
GT15-RS2-9P
GT01-RS4-M
*2
-
