6. DIRECT CONNECTION TO CPU
6.2 System Configuration
 When connecting to FX3GC (FX3GC-/D, FX3GC- /DSS) (RS-422 connection)
*1 For details of the GOT multi-drop connection, refer to the following.
18. GOT MULTI-DROP CONNECTION
 When connecting to FX3GC (FX3GC-/D, FX3GC- /DSS) (RS-232 connection)
*1 For details of the GOT multi-drop connection, refer to the following.
18. GOT MULTI-DROP CONNECTION
*2 A GOT and a peripheral such as a PC with GX Developer installed can be connected to the function adapter and the FXCPU
individually.
*3 When using function expansion boards or function adapters, confirm the communication settings.
6.5 Precautions Connection to FXCPU (2)When connecting with function extension board or communication special
adapter
PLC Connection cable GOT
Number of
connectable
equipment
Model name
Communication
type
Cable model
Max.
distance
Option device Model
FX3GC-/D
FX
3GC-/DSS
RS-422
GT01-C10R4-8P(1m)
GT01-C30R4-8P(3m)
GT01-C100R4-8P(10m)
GT01-C200R4-8P(20m)
GT01-C300R4-8P(30m)
30m
- (Built into GOT)
1 GOT for 1 PLC built-
in port
GT15-RS4-9S
GT01-RS4-M
*1
-
PLC Connection cable GOT
Number of
connectable
equipment
*2
Model name
Function
adapter
*3
Communication
type
Cable model
Connection diagram number
Max.
distance
Option device Model
FX
3GC-/D
FX
3GC-/DSS
FX
3U-232ADP RS-232
GT01-C30R2-9S(3m)
or
RS232 connection
diagram 1)
15m
- (Built into GOT)
1 GOT for 1
function
adapter
GT15-RS2-9P
GT01-RS4-M
*1
-

Mitsubishi GOT2000 Series Specifications

General

Power Supply	24VDC
Software	GT Works3
Processor	RISC CPU
Interface	Ethernet, USB, RS-232, RS-422/485
Operating Temperature	0°C to 50°C
Display Type	TFT LCD
Storage Temperature	-20°C to 60°C
Humidity	10% to 90% (non-condensing)
Shock Resistance	147 m/s² (15G), 11ms duration
Touch Panel	Analog Resistive
