8. BUS CONNECTION
8.1 Connectable Model List
8 - 3
8
BUS CONNECTION
(Continued to next page)
*1 Bus-connect the GOT on the last redundant extension base A68RB (version B or later) for the Q4ARCPU redundant system.
*2 When an extension base unit is connected, a bus connection cannot be established.
Series Model name Clock Communication type Connectable model Refer to
MELSEC-L
L02CPU
- -
L06CPU
L26CPU
L26CPU-BT
L02CPU-P
L06CPU-P
L26CPU-P
L26CPU-PBT
L02SCPU
L02SCPU-P
MELSEC-Q
(A mode)
Q02CPU-A
- -Q02HCPU-A
Q06HCPU-A
MELSEC-QnA
(QnACPU)
Q2ACPU
Bus connection
8.2.2
Q2ACPU-S1
Q3ACPU
Q4ACPU
Q4ARCPU
*1
MELSEC-QnA
(QnASCPU)
Q2ASCPU
Bus connection
8.2.3
Q2ASCPU-S1
Q2ASHCPU
Q2ASHCPU-S1
MELSEC-A
(AnCPU)
A2UCPU
Bus connection
8.2.2
A2UCPU-S1
A3UCPU
A4UCPU
A2ACPU
A2ACPUP21
A2ACPUR21
A2ACPU-S1
A2ACPUP21-S1
A2ACPUR21-S1
A3ACPU
A3ACPUP21
A3ACPUR21
A1NCPU
A1NCPUP21
A1NCPUR21
A2NCPU
A2NCPUP21
A2NCPUR21
A2NCPU-S1
A2NCPUP21-S1
A2NCPUR21-S1
A3NCPU
A3NCPUP21
A3NCPUR21
MELSEC-A
(AnSCPU)
A2USCPU
Bus connection
8.2.3
A2USCPU-S1
A2USHCPU-S1
A1SCPU
A1SCPUC24-R2
A1SHCPU
A2SCPU
A2SCPU-S1
A2SHCPU
A2SHCPU-S1
A1SJCPU
*2
A1SJCPU-S3
*2
A1SJHCPU
*2
MELSEC-A
A0J2HCPU
Bus connection
8.2.4
A0J2HCPUP21
