Mitsubishi GOT2000 Series Connection Manual

14 - 10
14. INVERTER CONNECTION
14.2 System Configuration
 When connecting to multiple inverters (Max. 31) (Using the control terminal option)
*1 The control terminal option and the PU port cannot be used at the same time.
FREQROL 500/700/800,
SENSORLESS SERVO
Communication driver
GOT
Connection cable
Control
terminal
option
Control
terminal
option
Inverter
Sensorless
servo
Inverter
Sensorless
servo
Inverter Connection cable GOT
Max.
distance
Number of
connectable
equipment
Model name
Control terminal
option
Communi
cation
type
Connection diagram
number
Option device Model
FREQROL-E700/
sensorless servo
(FREQROL-E700EX)
*2
FR-E7TR
*2
RS-485
RS485
connection diagram
8)
- (Built into GOT)
500m
31 inverters for
one GOT
*3
GT15-RS4-9S
