Mitsubishi GOT2000 Series Connection Manual

19. MULTI-CHANNEL FUNCTION
19.3 GOT Side Settings
19 - 17
19
MULTI-CHANNEL FUNCTION
 GOT interface used for bus connection
For the bus connection, use the following communication units.
*1 To mount multiple units, the GT15-QBUS(2) or GT15-ABUS(2) is required.
POINTPOINTPOINT
(1) Bus connection units to be used
GT15-QBUS(2) and GT15-ABUS(2) can be used independent of the number of serial connection channels.
When using the multi-channel function for the first time, it is recommended to use GT15-QBUS(2) or GT15-
ABUS(2).
(2) Restrictions by bus connection unit installation
For the following functions, use the GT15-QBUS(2) or GT15-ABUS(2), regardless of the number of channels
used for the serial connection.
With the GT15-75QBUS(2)L or GT15-75ABUS(2)L, the following functions are not available.
 GOT interface used for network connection
For the network connection, use the following communication units.
 GOT interface used for Ethernet connection
For the Ethernet connection, use the following interface built in the GOT and communication unit.
*1 Up to four channels can be used.
 GOT interface used for serial connection
For the serial connection, provide interfaces equivalent to the number of channels by using the following interfaces
built in the GOT and communication units in combinations.
*1 The operator authentication (external authentication) or the FA transparent function (RS-232 communication) uses the RS-232
interface built in the GOT.
Interface
Model
*1
Bus connection unit
GT15-75QBUS(2)L, GT15-75ABUS(2)L, GT15-QBUS(2),
GT15-ABUS(2)
Function
Remote personal computer operation (serial), Video display function, Multimedia function,
External I/O function, RGB display function, Sound output function
Interface Model
MELSECNET/H communication unit GT15-J71LP23-25,GT15-J71BR13
CC-Link IE Controller Network communication unit GT15-J71GP23-SX
CC-Link IE Field Network communication unit GT15-J71GF13-T2
CC-Link communication unit GT15-J61BT13
Interface Name
Name
Ethernet interface
*1
Interface Name/model
Interface built in GOT
RS-232 interface
*1
, RS-422/485 interface
Serial communication module GT15-RS2-9P,GT15-RS4-9S,GT15-RS4-TE

Mitsubishi GOT2000 Series Specifications

General

Power Supply	24VDC
Software	GT Works3
Processor	RISC CPU
Interface	Ethernet, USB, RS-232, RS-422/485
Operating Temperature	0°C to 50°C
Display Type	TFT LCD
Storage Temperature	-20°C to 60°C
Humidity	10% to 90% (non-condensing)
Shock Resistance	147 m/s² (15G), 11ms duration
Touch Panel	Analog Resistive
