ValueJet 1304 Service manual
4-65 AP-74109 Rev 1.1
12. Remove the damper locating material-retaining screw (round head spring screw M3 × 6 W sems: 2).
13. Remove the damper locating material.
表 4-73
No. Part name
1 Flat-head driver insertion point
2
Damper assembly
表 4-74
No. Part name
1 Damper locating material
2
Damper locating material screw
(round head spring screw M3
×
6 W sems)
1
2
1
2
