ValueJet 1304 Service manual
4-71 AP-74109 Rev 1.1
2. Remove the P_EDGE sensor assembly-retaining screw (M3 × 6, P tight cup: 1).
3. Detach the cable from the three clamps.
4. Remove the P_EDGE sensor assembly.
5. To reassemble the unit, reverse the removal procedure.
表 4-80
No. Part name
1 P_EDGE sensor assembly
screw
(M3
× 6, P tight cup)
2
P_EDGE sensor assembly


