ValueJet 1304 Service manual
4-73 AP-74109 Rev 1.1
2. Pull up the pressure lever.
3. Remove the lock bracket-retaining screw (tapping screw M3 × 6, S cup tight: 1).
4. Remove the cable on the maintenance base 1 from the clamps.
表 4-82
No. Part name
1 Pressure lever
表 4-83
No. Part name
1 Head lock-retaining screw
(tapping screw M3
× 6, S cup
tight)
2
Head lock
1
1
2

MUTOH ValueJet Specifications

General

Technology	Piezo Inkjet
Ink Type	Eco-solvent ink
Print Resolution	Up to 1440 dpi
Resolution	Up to 1440 dpi
Ink Colors	CMYK, White
Media Width	64 inches
Interface	USB, Ethernet
Operating Systems	Windows
