ValueJet 1304 Service manual
AP-74109 Rev 1.1 4-74
5. Remove the motor relay connector.
6. Remove the wiper phase sensor connector.
7. Remove the maintenance base 1 front part-retaining screw (tapping screw M3
× 6, S tight cup: 2).
表 4-84
No. Part name
1 Motor relay connector
2
Clamp
表 4-85
No. Part name
1
Wiper phase sensor connector
2
Pump unit
1
2
1
2
