ValueJet 1304 Service manual
4-75 AP-74109 Rev 1.1
8. Remove the maintenance base 1 rear part-retaining screw (tapping screw M3 × 6, S tight cup: 2).
表 4-86
No. Part name
1
Maintenance base 1-retaining
screw (tapping screw M3
× 6, S
tight cup)
2
Maintenance base 2
表 4-87
No. Part name
1
Maintenance base 1-retaining
screw (tapping screw M3
× 6, S
tight cup)
2
Maintenance base 1
1
2
1
2
