ValueJet 1304　Service manual
4-111 AP-74109 Rev 1.1
2. Detach the motor cable, W_ON sensor relay assembly and the W_OFF sensor relay assembly from the
connector to the VJ take up unit CNT board assembly that appears.
3. To reassemble the unit, reverse the removal procedure.
表 4-132
No. Part name
1 VJ take up unit CNT board
assembly
2 Motor cable
3 W_ON sensor relay assembly,
the W_OFF sensor relay
assembly
1
2
3
