MUTOH ValueJet User Manual

ValueJet 1304 Service manual
AP-74109 Rev 1.1 7-6
T fence 1 CR encoder inspection "5.5.5 Encoder
Menu" p.5-17
2 Uni-D / Bi-D Low Adjustment
Uni-D / Bi-D High Adjustment
"5.7.6 Uni-D / Bi-D
Low and High
Adjustment" p.5-36
3 Side margin adjustment "5.7.7 Side Margin
Adjustment Menu"
p.5-42
4 Test printing "5.7.8 Test
Printing Menu" p.5-43
CR driven pulley 1 CR belt tension adjustment "7.6 CR Belt
Tension Adjustment"
p.7-35
Cutter holder
assembly
1 Cutter holder assembly mounting
position adjustment
"7.9 Cutter Holder
Height Adjustment"
p.7-40
2 P_EDGE sensor adjustment "7.11.1 P_EDGE
Sensor Sensitivity
Adjustment" p.7-45
3 Print margin adjustment "5.7.7 Side Margin
Adjustment Menu"
p.5-42
Carriage assembly 1 CR belt tension adjustment "7.6 CR Belt
Tension Adjustment"
p.7-35
2 CR encoder inspection "5.5.5 Encoder
Menu" p.5-17
3 Cutter holder assembly mounting
position adjustment
"7.9 Cutter Holder
Height Adjustment"
p.7-40
4 P_EDGE sensor adjustment "7.11.1 P_EDGE
Sensor Sensitivity
Adjustment" p.7-45
5 Sequential printing endurance operation
check
"5.13.4 Print Head
Endurance (Nozzle
Print) Menu" p.5-71
Table 7-1 Adjustment Item List (Continued)
Part replaced or
adjusted
Adjustment
order
Adjustment item Reference
