Carriage assembly
(Continued)
6
Head rank input
"(1) Head Rank"
p.5-57
"5.13.4 Print Head
Endurance (Nozzle
Print) Menu" p.5-71
7 Print margin adjustment "5.7.7 Side Margin
Adjustment Menu"
p.5-42
8 Head nozzle check "5.7.2 Head Nozzle
Check Menu" p.5-26
9 Head slant check (horizontal) "5.7.4 Head Slant
Check Menu" p.5-29
10 Head slant check (vertical) "5.7.4 Head Slant
Check Menu" p.5-29
11 Head slant adjustment (horizontal) "7.7 Head
Alignment (Horizontal
Height)" p.7-36
12 Head slant adjustment (vertical) "7.8 Head
Alignment (Vertical
Slant)" p.7-38
13 Uni-D / Bi-D Low Adjustment
Uni-D / Bi-D High Adjustment
"5.7.6 Uni-D / Bi-D
Low and High
Adjustment" p.5-36
14 Test printing "5.7.8 Test
Printing Menu" p.5-43
Table 7-1 Adjustment Item List (Continued)
Part replaced or
adjusted
Adjustment
order
Adjustment item Reference
