MUTOH ValueJet User Manual

ValueJet 1304 Service manual
AP-74109 Rev 1.1 9-6
1 Undefined
Media
Media
detection failed
7. Check presence of
media from "Sen
7:Rear" of self-
diagnosis function.
When "Media End" is
displayed even if media
is set, replace P_REAR
sensor.
"4.9.2
Replacing
P_REAR
Sensor
Assembly"
p.4-90
8. Main board
assembly may be
damaged.
Replace main board
assembly.
"4.3.3
Replacing
Main Board
Assembly"
p.4-29
2 Media Slant Media is
running
obliquely.
1. Set media again and
check reappearance.
If this error is caused by
user's inappropriate
media setting, instruct
correct media setting
procedure.
-
2. Is suction fan works
normally when
checked through
“Fan1: Vacum Fan”
of "Test6: Fan" of
self-diagnosis
function?
- Check connection of
following main board
assembly connectors.
• Suction fan 1 cable:
J128
• Suction fan 2 cable:
J127
• Suction fan L cable:
J126
• Replace suction fan
assembly.
• Replace cable of
suction fan that does
not operate
normally.
"4.9.1
Replacing
Suction Fan
Assembly"
p.4-89
3. Is shielding material
secured at specified
position?
Remount it at specified
position.
-
4. Check pressure
lever operation.
Apply grease (G501) to
pressure cam and make
adjustment.
"8.4
Lubrication/
Bonding"
p.8-7
5. Is P_EDGE sensor
assembly cable at
head connected
correctly?
Securely connect it to
CR board assembly
connector J211.
"4.10.1
Replacing CR
Board
Assembly"
p.4-91
Table 9-3 Events and Check Items for Errors with Messages (Continued)
No. Message Event/
symptom
Check item Action Reference
