ValueJet 1304 Service manual
9-7 AP-74109 Rev 1.1
2 Media Slant Media is
running
obliquely.
6. Check sensor
sensitivity from
"Sen 6:EdgeAD" of
self-diagnosis
function.
• Adjust with main
board assembly
volume (R361,
R365).
• Replace P_EDGE
sensor assembly.
"7.11.1
P_EDGE
Sensor
Sensitivity
Adjustment"
p.7-45
3
[KCMY]
Ink Near End
[KCMY]
Ink End
Ink is running
short. Printing
is possible.
Ink has run out.
Any printing
operation stops
immediately.
1. Check contact of the
ink sensor
assembly.
Reconnect following
connectors.
MAIN board: J43
HEATER JUNCTION
board:
• Connector J5(K)
• Connector J6(C)
• Connector J7(M)
• Connector J8(Y)
"4.3.3
Replacing
Main Board
Assembly"
p.4-29
2. For the ink color
that is displayed as
"Ink Near End" or
"Ink End", switch
ink sensor assembly
connector with that
of normally
displayed ink color.
• If ink color display
changes after
replacing
connector:
Ink sensor assembly
is damaged.
Replace ink sensor
assembly.
• If ink color display
does not change
after replacing
connector:
JUNCTION board
assembly may be
damaged.Replace
JUNCTION board
assembly.
"4.8.1
Replacing
Ink Holder (I/
H)
Assembly"
p.4-79
"4.3.3
Replacing
Main Board
Assembly"
p.4-29
4[KCMY]
No Cartridge
Cartridge is not
installed.
1. Turn machine OFF.
Turn it ON again
and check if the
same message
appears.
If message appears:
Refer to action in check
item No. 2.
-
2. Check contact of
ink NOT sensor
assembly
connector.
Reconnect following
connectors.
MAIN board: J43
HEATER JUNCTION
board:
• Connector J5(K)
• Connector J6(C)
• Connector J7(M)
• Connector J8(Y)
"4.3.3
Replacing
Main Board
Assembly"
p.4-29
Table 9-3 Events and Check Items for Errors with Messages (Continued)
No. Message Event/
symptom
Check item Action Reference
