ValueJet 1304 Service manual
AP-74109 Rev 1.1 9-8
4[KCMY]
No Cartridge
Cartridge is not
installed.
3. For the ink color
that is displayed as
"Little ink" or "No
ink", switch ink
NOT sensor
assembly connector
with that of
normally displayed
ink color.
If ink color displayed as
"No ink" changes after
replacing connector:
Ink sensor assembly is
damaged. Replace ink
sensor assembly.
"4.8.1
Replacing
Ink Holder (I/
H)
Assembly"
p.4-79
If ink color displayed as
"No ink" does not
change after replacing
connector:
JUNCTION board
assembly may be
damaged.Replace
JUNCTION board
assembly.
"4.3.3
Replacing
Main Board
Assembly"
p.4-29
5[KCMY]Not
Original
Specified ink
cartridge is not
installed.
1. Check if the same
message appear if
turning machine
OFF and turn it ON
again.
If the message appears:
Refer to the action in
check item No. 2.
-
2. Check if specified
ink cartridge is
used.
Replace ink cartridge
with specified one.
Operation
Manual
3. Check if a new ink
cartridge is detected
normally while
pushing in / pulling
out the cartridge.
If detection does not
operate normally,
replace following parts.
• Ink sensor assembly
• Main board assembly
"4.8.1
Replacing
Ink Holder (I/
H)
Assembly"
p.4-79
"4.3.3
Replacing
Main Board
Assembly"
p.4-29
4. Check contact of
ink ID sensor
assembly
connector.
- Reconnect following
main board assembly
connectors.
MAIN board: J43
HEATER JUNCTION
board:
• Connector J5(K)
• Connector J6(C)
• Connector J7(M)
• Connector J8(Y)
If no change occurs,
proceed to step (5).
"4.3.3
Replacing
Main Board
Assembly"
p.4-29
Table 9-3 Events and Check Items for Errors with Messages (Continued)
