ValueJet 1304　Service manual
AP-74109 Rev 1.1 2-10
(2) LCD Monitor and Status Lamps
8 [Power] key Turns the printer on and off. Turns the printer on and off.
No. Name Color Status Function
9 Power lamp Green On The printer is switched on.
Blinking An error has occurred. The contents will be displayed on the
LCD monitor.
Off The printer is switched off.
10 Data lamp Red On - The printer is analyzing received data.
- The printer is printing data.
Blinking The printer is receiving data.
Off The printer is not receiving, analyzing or printing data.
11 High lamp Green On The print head height is set to High position.
Off The print head height is set to Low position.
12 Low lamp Green On The print head height is set to Low position.
Off The print head height is set to High position.
13 Wave lamp Red On The effect menu is set to Wave.
Off The effect menu is set to either Fine or SuperFine.
14 Fine & S.Fine
lamp
Red On The effect menu is set to either Fine or SuperFine.
Off The effect menu is set to Wave.
15 Strong lamp Green On - The cleaning mode is set to Strong.
- When the Normal lamp is also on, the cleaning mode is set
to Economy.
Off - The effect menu is set to Wave.
- When the Strong lamp is also on, the cleaning mode is set
to Economy quality.
16 Normal lamp Green On - The cleaning mode is set to Normal.
- When the Strong lamp is also on, the cleaning mode is set
to Economy quality.
Off The cleaning mode is set to Strong.
17 LCD monitor - - This monitor displays the operation status and error
messages of the printer.
No. Name Normal Setup menu display
