ValueJet 1304 Service manual
4-9 AP-74109 Rev 1.1
8. Remove the R side cover rear screw (tapping screw M4 × 12, S tight cup: 2).
9. Return the pressure lever forward and remove the R side cover to the upper right direction.
10. Replace the parts inside the product.
11. To reassemble the unit, reverse the removal procedure.
表 4-6
No. Part name
1 R side cover
2 R side cover rear screw
(tapping screw M4
× 12, S tight
cup)
