ValueJet 1304　Service manual
4-27 AP-74109 Rev 1.1
Table 4-26 Connectors to Main Board Assembly
No. Connector
No.
# of pins Color Connect to Remarks
1 J1 14 White Power board assembly Connected to CN301 by using
DC cable assembly.
2 J5 FFC Black Operation panel unit assembly
3 J9 FFC Black CR board assembly J203 Connected to J203 by using CR
tape wire.
4 J10 FFC Black CR board assembly Connected to J202 by using CR
tape wire.
5 J11 FFC Black CR board assembly Connected to J201 by using CR
tape wire.
6 J12 4 White PF ENC assembly -
7 J14 - - Unused -
8 J15 - - Unused -
9 J16 - - Unused -
10 J17 - - Unused -
11 J20 2 White PF motor assembly -
12 J21 3 White CR motor assembly -
13 J22 4 White Pump motor assembly -
14 J23 - - Unused -
15 J24 3 White CR_ORG sensor -
16 J25 2 White Suction fan 1 assembly -
17 J26 2 Black Suction fan 2 assembly
-
18 J27 3 Black Wiper origin sensor -
19 J28 2 Red Suction fan 3 assembly
-
20 J29 2 Yellow Suction fan 4 assembly -
21 J30 3 Blue Lever sensor assembly -
22 J28 2 White Cooling fan (5V) assembly -
23 J29 3 Red Waste fluid level switch (VJ16) -
24 J36 2 Red Cooling fan (24V) assembly -
25 J38 3 Yellow Cover R sensor -
26 J40 4 Blue Cover L sensor -
27 J41 - - Unused -
28 J42 4 Black P_REAR sensor -
29 J43 8 - HEATER CONT board -
30 J45 - - Unused -
To Next Page
