ValueJet 1304 Service manual
4-29 AP-74109 Rev 1.1
4. Remove the board bracket-retaining screws (tapping screw M3 × 6, S tight cup: 5).
5. Slide the main board bracket to the right then lift from the front side and remove it.
表 4-27
No. Part name
1 Main board bracket
2 Main board bracket-retaining screw
(tapping screw M3
× 6, S tight cup)
1
2
2
