ValueJet 1304 Service manual
AP-74109 Rev 1.1 4-32
3. Replace the following parts;
AC cable assembly between CNT - RLY
Tape wire between CNT - RLY
DC cable assembly between MAIN - CNT
Serial cable between MAIN - CNT
AC cable between CNT - Power unit
DC cable between CNT - Power unit
11 J12 - - - Unused
12 J13 - - - Unused
13 J14 - - - Unused
14 J15 - - - Unused
15 J16 - - - Unused
16 J17 - - - Unused
17 J18
- - - Unused
18 J19 8 White Main board assembly Connected to J46 by using
power cable assembly between
MAIN - CNT.
19 J20 - -
- Unused
20 J21 - - - Unused
21 J22 2 White Terminal block AC cable between terminal
block and CNT
22 J23 2 White HEATER RELAY AC cable assembly between
CNT - RLY
Table 4-30 Connectors to HEATER CONT board assembly (Continued)
No. Connector
No.
# of
pins
Color Connect to Remarks

MUTOH ValueJet Specifications

General

Technology	Piezo Inkjet
Ink Type	Eco-solvent ink
Print Resolution	Up to 1440 dpi
Resolution	Up to 1440 dpi
Ink Colors	CMYK, White
Media Width	64 inches
Interface	USB, Ethernet
Operating Systems	Windows
