TIP
• When reassembling the cooling fan, spread the fan seal (shown in the diagram below) under the
fan, then screw the fan on it
• Installation direction of the cooling fan assembly (sealing surface and cable pulling direction) is
specified. Install it with the sealing surface facing up.
表 4-48
No. Part name
1 Fan seal
1
