2.2 Troubleshooting with Error Messages VJ628XE-M-00
2.2.3 Errors Requiring Reboot 30
13 E077 Err
Platen heat system
An anomaly is detected
in Platen heater system
(Thermistor, Heater).
Thermistor or Heater’s connector may be
disconnected, wiring may be faulty, or Thermistor
cable maybe nipped by plates, or Heater may be
damaged.
1. Plug Thermistor or Heater’s connector
properly.
2. Check the connections of HEATER DRIVE
board.
3. Replace HEATER DRIVE board.
4. Replace Heater.
-
14 E081 Err
CR Origin
CR origin cannot be
detected.
1. Check CR origin sensor in “Sen.: CR Origin”
in the self-diagnosis function.
(Check if “ON” is displayed when Carriage is
locked and “OFF” is displayed when
Carriage is moved.)
Check connection of CR origin sensor cable
connector.
"5.4.4Sensor Menu
2. CR origin sensor may be damaged. Replace it. "3.6.4Replacing CR Origin
Sensor
3. JUNCTION board may be damaged. Replace it. "3.5.11Replacing JUNCTION
Board
15 E 085 Err
Head Heat
An anomaly is detected
in Head driver.
1. Check the connection of Head FFC.
2. Check the connection of CR_FFC.
3. Head FFC may be damaged.
4. CR_FFC may be damaged.
5. Head may be damaged.
6. CR board may be damaged.
7. MAIN board may be damaged.
1. Make sure to connect Head FFC surely.
2. Make sure to connect CR_FFC surely.
3. Replace Head FFC.
4. Replace CR_FFC.
5. Replace Head.
6. Replace CR board.
7. Replace MAIN board.
3.8.16 Replacing Head FFC
3.9.3 Replacing CR FFC
3.8.15 Replacing Head
"3.5.10Replacing MAIN Board
16 E 087 Err
H trans Th.
This indicates that Head
transistor is
malfunctioning.（The
temperature of Head
transistor of MAIN board
may be abnormal, or the
sensor of Thermistor
may be malfunctioning.)
17 E 090 Err
Heater Volt.
An anomaly is detected
in Heater Volt.
1. Check input voltage.
2. HEATER DRIVE board may be malfunction.
Replace HEATER DRIVE board. "3.11.6Replacing HEATER
DRIVE Board
18 E097 Err
NVRAM.
An anomaly is detected
in NVRAM.
- Replace MAIN board.
"3.5.10Replacing MAIN Board
19 E140Err
Pre heat Th.
An anomaly is detected
in Pre Thermistor.
1. Pre Thermistor connector may be
malfunctioning.
2. Thermistor may be disconnecting.
3. HEATER DRIVE board may be
malfunctioning.
1. Make sure to connect thermistor connector
securely.
2. Replace Pre Thermistor relay.
3. Replace Pre Thermistor.
4. Replace DRIVE board.
-
Table 2-4 Symptoms and Check Items for Mechanical Serious Errors(Continued)
No. Message Event/symptom Check item Action Reference
