8.2.2 Operation panel 385
8.2 Part Names and Functions VJ628XE-M-00
(2-b)Display section
7 [Forward↓] key Media is fed in the forward
direction.
-
[–] key - • Changes to the previous item
in the displayed setting.
• The setting is changed to the
reverse direction.
• The numeric value is
decreased during numerical
input.
8 [Power] key Turns printer ON and OFF. Turns printer ON and OFF.
No. Name Color Status Description
9 Power lamp Blue Lamp
ON
Power ON.
Lamp
blinks
• Data is received and analyzed.
• Performing media initial operation.
Lamp
OFF
Power OFF.
10 Error lamp Oran
ge
Lamp
ON
An error has occurred
The error content is displayed on the LCD
Lamp
blinks
The remaining amount of ink is low.
Lamp
OFF
There is no error.
11 Heater Link
lamp
Gree
n
Lamp
ON
Blower heater is in the "Printer Link" condition.
Lamp
OFF
Blower heater is in the "Manual" condition.
12 Origin lamp Gree
n
Lamp
ON
"Origin" is activated.
Lamp
OFF
“Origin” is deactivated.
No. Name Normal Setup menu display
13 Roll lamp Gree
n
Lamp
ON
“Roll media” is set as “Media type”.
14 Rigid lamp Gree
n
Lamp
ON
“Media type” is set as “Rigid”.
15 Long lamp Gree
n
Lamp
ON
• Cleaning Mode is set to Long.
• When the Normal lamp is also turned on, Cleaning
Mode is set to Short.
Lamp
OFF
Cleaning Mode is set to Normal.
16 Normal lamp Gree
n
Lamp
ON
• Cleaning Mode is set to Normal.
• When the Long lamp is also turned on, Cleaning
Mode is set to Short.
Lamp
OFF
Cleaning Mode is set to Long.
17 LCD display
section
- - Displays operation status of the printer or an error
message.
No. Name Color Status Description
