Operation

IndicatorsaboutDEFQualityProblem(ForVehiclesEquippedwithCummins

X15Engines)

LevelIndicationAudibleAlarmLCDTextMessageVehicleConditions/Operation

1 1beep

ScrollsbetweenDEFQUALITY

SERVICESOONandWARN

ENGINE.

InitialWarning–faultcodehasbeen

set.

2 1beep

ScrollsbetweenDEFQUALITY

DERATED25%andWARN

ENGINE.

Engineperformanceisderatedbyat

least25%.

3 1beep

ScrollsbetweenDEFQUALITY

DERATED40%andWARN

ENGINE.

Engineperformanceisprogressively

deratedbyupto40%.

4 1beep

ScrollsbetweenDEFQUALITY

DERATED5MPH,WARN

ENGINE,andSTOPENGINE.

Engineperformanceisderatedby

40%.Vehiclespeedislimitedto5

mph(8km/h).
