Operation

WarningsofSCRSystemFault(ForVehiclesEquippedwithCummins

X15Engines)(cont.)

LevelIndicationAudibleAlarmVehicleConditions/Operation

and

1beep

Engineperformanceisderatedby40%.Vehiclespeedislimitedto5

mph(8km/h).

186
