Controls/Features

SwitchIconDescription

2/7 Partoftheanti-theftsystem.

3/8 Partoftheanti-theftsystem.

4/9 Partoftheanti-theftsystem.

Traction

ControlOff

Road

Enablesanddisablesthe

AntilockBrakeSystem(ABS)

tractioncontrolfeature.

SwitchIconDescription

InhibitRegen

RegenerationInhibitswitch.

Usedtopreventnormal

regenerationorparked

regeneration.

ParkedRegen

DPFregenerationactivation

whenparkedswitchisused

forengineaftertreatment.

ManuallyinitiatesDPF

regeneration.

HillStartAid

Assistsdriveringettingthe

vehicleinmotiononahill.

PTO1

Usedwhenvehiclehasdual

PTOoption.
