Controls/Features

SwitchIconDescription

Heated

Windshield

Activatesthewindshield

heater.

Differential

LockFront

Rear

Locksforwardreardriveaxle

differentialwhenvehiclehas

6x4independentlocking

differentialsforimproved

tractiononpoorsurfacesatlow

speeds.

Differential

LockRear

Rear

Locksreardriveaxle

differentialwhenvehicle

has6x4independentlocking

differentialsforimproved

tractiononpoorsurfacesatlow

speeds.

5thWheel

Unlock

Pressandholdthismomentary

switchtounlockthefthwheel

jaw.Vehiclemustbestationary,

parkingbrakeset,andignition

switchintheONposition.

SwitchIconDescription

120VAC

Providespowertothesleeper

ACelectricaloutlet.

EngineSTOP

/CLEAR

Engineshutoff.

0/5 Partoftheanti-theftsystem.

1/6 Partoftheanti-theftsystem.
