displayed, T-Bar lighting is at its brightest. Removing the layer dims the
illumination.
22.3.12 MAIN TRANSITION
1. Just as you would expect, the illumination of this T-Bar uses red-green coloration,
standard color coding for Program and Preview rows.
2. As for M/Es, described earlier, DSK-only delegate operations result in the T-Bar
being lit in purple.
3. Mixed mode (BKGD plus DSK delegates) likewise result in blue illumination, just
like the M/E T-Bar behavior previously described.
22.3.13 PTZ CONTROL
Pan, tilt, zoom control over connected robotic cameras is also provided using the
joystick.
Note: Joystick operations do not affect stored PTZ preset values.
To delegate the joystick to control a PTZ camera assigned to a specific TriCaster input,
hold down SHIFT button on the control surface and press a button (1-8) in the M/E
Delegate group. (Afterward, the button corresponding to the current PTZ camera
selection will light whenever SHIFT is pressed.)
Pan: With SHIFT depressed, tilt the joystick left-right.
Tilt: With SHIFT depressed, tilt the joystick backward-forward.
Zoom: With SHIFT depressed, twist the joystick clockwise or counter-
clockwise.
Focus: When Auto is off, and with SHIFT + CTRL both pressed, twist the
joystick clockwise or counter-clockwise.
o Auto Focus toggle: With SHIFT + CTRL held down, press the joystick
button.
