22.7.13 EQ CONTROL
TriCaster provides independent 7-band equalization along with
Compressor/Limiter features for each source. And Artist Mix lets
you access the controls without ever touching the TriCaster user
interface.
To display EQ controls, it will probably come as no surprise by this
point that you need to push the EQ button in the Knob Set control
group.
FIGURE 384
The OLED display will now appear as seen in Figure 384. Normally, all 7 bands for a
single input are shown in this manner. In this mode, the knobs below the graph in
each group control the setting for a single EQ band, shown above.
Note that the label for one input is highlighted in the OLED display. (For example,
Figure 385 shows a highlight behind the Line 1 label; Line 2 is not highlighted.)
FIGURE 385
This highlight identifies the currently selected source. Any adjustments made in this
state affect the EQ settings for the selected source only. In this fashion, you can easily
adjust all settings for one source. To select a particular source (such as Input 1 or 2)
for adjustment, press the button labeled SEL to the left of the fader in the control
surface slot with the corresponding label above.
The highlight in the OLED display updates to show the newly selected source.
