Page | 33
b. Component – Attach your device to the second, third and fourth BNC
connectors (Y, Pb and Pr).
c. Y/C – If your S-Video equipment and cabling has the usual 4-pin mini-DIN
connectors, you will need an ‘S-Video to dual BNC’ adapter.
i. Attach the Y (luma) connector of your device to the second analog
BNC connector row (labeled Pb at far left in the VIDEO IN group).
ii. Attach the C (chroma) connector to the third analog connector
(labeled Pr).
d. Composite – Attach the device’s connector to the first (top) analog
connector (just above the pair labeled Y/C).
2. Connect TriCaster’s audio outputs:
a. Analog audio – Connect external audio devices to the connectors in the
AUDIO OUT section.
8-input TriCasters offer two pairs of four audio output connectors:
i. Connectors 1a-(1b or 1d) provide sound from the mix assigned to
Output 1 (defaults to Master in Output Configuration)
ii. Connectors 2a-(2b or 2d) provide sound from the mix assigned to
Output 2 (defaults to Aux in Output Configuration)
Note: These two output groups are actually treated by TriCaster as four
independent stereo outputs, each configured and controlled separately;
see Chapter 15, Audio.
b. Digital audio – A separate digital audio connection is not necessary for SDI
or HDMI output with embedded audio. AES/EBU connectors are provided
for Output 1(channels a-d) on 8-input models.
Hint: TriCaster’s SDI and analog output sections can be used simultaneously. For
example, you could use the Composite output to view your program on a local composite
monitor at the same time as you use the SDI connection to supply broadcast equipment.
