R&S FSW Series User Manual

Remote Commands
R&S
®
FSW
1170User Manual 1173.9411.02 ─ 43
Manual operation: See "Marker Table" on page 502
See "Marker Peak List" on page 502
14.8.3.6 Marker Search (Spectrograms)
The following commands automatically define the marker and delta marker position in
the spectrogram.
The usage of these markers is demonstrated in Chapter 14.8.2.7, "Programming
Example: Configuring a Spectrogram", on page 1148.
Using Markers
The following commands control spectrogram markers.
Useful commands for spectrogram markers described elsewhere
The following commands define the horizontal position of the markers.
●
CALCulate<n>:MARKer<m>:MAXimum:LEFT on page 1163
●
CALCulate<n>:MARKer<m>:MAXimum:NEXT on page 1163
●
CALCulate<n>:MARKer<m>:MAXimum[:PEAK] on page 1163
●
CALCulate<n>:MARKer<m>:MAXimum:RIGHt on page 1163
●
CALCulate<n>:MARKer<m>:MINimum:LEFT on page 1164
●
CALCulate<n>:MARKer<m>:MINimum:NEXT on page 1165
●
CALCulate<n>:MARKer<m>:MINimum[:PEAK] on page 1165
●
CALCulate<n>:MARKer<m>:MINimum:RIGHt on page 1165
Remote commands exclusive to spectrogram markers
CALCulate<n>:MARKer<m>:SGRam:FRAMe................................................................. 1171
CALCulate<n>:MARKer<m>:SPECtrogram:FRAMe.........................................................1171
CALCulate<n>:MARKer<m>:SGRam:SARea.................................................................. 1171
CALCulate<n>:MARKer<m>:SPECtrogram:SARea..........................................................1171
CALCulate<n>:MARKer<m>:SGRam:XY:MAXimum[:PEAK].............................................1172
CALCulate<n>:MARKer<m>:SPECtrogram:XY:MAXimum[:PEAK].....................................1172
CALCulate<n>:MARKer<m>:SGRam:XY:MINimum[:PEAK].............................................. 1172
CALCulate<n>:MARKer<m>:SPECtrogram:XY:MINimum[:PEAK]......................................1172
CALCulate<n>:MARKer<m>:SGRam:Y:MAXimum:ABOVe...............................................1172
CALCulate<n>:MARKer<m>:SPECtrogram:Y:MAXimum:ABOVe.......................................1172
CALCulate<n>:MARKer<m>:SGRam:Y:MAXimum:BELow............................................... 1172
CALCulate<n>:MARKer<m>:SPECtrogram:Y:MAXimum:BELow.......................................1172
CALCulate<n>:MARKer<m>:SGRam:Y:MAXimum:NEXT.................................................1172
CALCulate<n>:MARKer<m>:SPECtrogram:Y:MAXimum:NEXT.........................................1172
CALCulate<n>:MARKer<m>:SGRam:Y:MAXimum[:PEAK]............................................... 1173
CALCulate<n>:MARKer<m>:SPECtrogram:Y:MAXimum[:PEAK].......................................1173
CALCulate<n>:MARKer<m>:SGRam:Y:MINimum:ABOVe................................................1173
CALCulate<n>:MARKer<m>:SPECtrogram:Y:MINimum:ABOVe........................................1173
