Parameters:
<Frequency> Possible frequencies of the calibration signal are fix.
If you define a frequency that is not available, the R&S FSW
uses the next available frequency. Example: a frequency of
20 MHz is rounded up to the next available frequency (25 MHz).
*RST: 50 MHz
Default unit: Hz
Manual operation: See "Calibration Frequency RF" on page 715
DIAGnostic:SERVice:INPut:PULSed:MCFRequency
<Frequency>
This command sets the calibration frequency for frequencies greater than 7 GHz. This
command only takes effect if a microwave calibration signal is selected for input
(DIAGnostic:SERVice:INPut[:SELect] on page 1266).
Parameters:
<Frequency> *RST: 7 GHz
Default unit: Hz
Example:
DIAG:SERV:INP:PULS:MCFR 7,1 GHz
DIAGnostic:SERVice:INPut:PULSed:WBFRequency <Frequency>
Defines the frequency of the internal broadband calibration signal to be used for IF fil-
ter calibration.
This command is only available if the bandwidth extension option R&S FSW-B160 is
installed.
Before you can use the command, you have to feed in a calibration signal with
DIAGnostic:SERVice:INPut[:SELect] on page 1266.
Parameters:
<Frequency> 2 MHz | 4 MHz | 8 MHz | 16 MHz
If you define a frequency that is not available, the R&S FSW
uses the next available frequency.
*RST: 16 MHz
Default unit: Hz
Example:
DIAG:SERV:INP:PULS:WBFR 8 MHz
Defines a calibration signal frequency of 8 MHz.
Example:
DIAG:SERV:INP:SEL WBC
DIAG:SERV:INP:PULS:WBFR 4MHz
DIAGnostic:SERVice:INPut:RF[:SPECtrum] <Bandwidth>
This command selects the bandwidth of the calibration signal.
Parameters:
<Bandwidth> NARRowband | BROadband
