R&S FSW Series User Manual

Remote Commands
R&S
®
FSW
1285User Manual 1173.9411.02 ─ 43
[SENSe:]CORRection:FRESponse<si>:BASeband:USER:SLISt<sli>:SELect
<FilePath>
[SENSe:]CORRection:FRESponse<si>:INPut<ip>:USER:SLISt<sli>:SELect
<FilePath>
[SENSe:]CORRection:FRESponse<si>:USER:SLISt<sli>:SELect <FilePath>
Selects a Touchstone format file from the specified directory to be loaded to the current
configuration for the specified input type. If no input type is specified, the currently
active input source is assumed.
To determine which files are available, use [SENSe:]CORRection:
FRESponse<si>:USER:SLISt<sli>:CATalog? on page 1280.
Suffix:
<si>
.
1..n
irrelevant
<sli> 1..n
Index in Touchstone file list
Use [SENSe:]CORRection:FRESponse<si>:USER:
SLISt<sli>:SIZE? to determine the maximum index number.
To replace an existing file in the configuration, specify its index.
To add a new file, use the next available index.
If an index outside the available range is specified, an error
occurs.
Parameters:
<FilePath> string
Path and file name
The default directory for Touchstone files is C:\R_S\INSTR
\USER\Fresponse.
Example:
SENS:CORR:FRES:USER:SLIS:SEL 'C:\FRes21.s2p'
[SENSe:]CORRection:FRESponse<si>:BASeband:USER:SLISt<sli>:SIZE?
[SENSe:]CORRection:FRESponse<si>:INPut<ip>:USER:SLISt<sli>:SIZE?
[SENSe:]CORRection:FRESponse<si>:USER:SLISt<sli>:SIZE?
Queries the number of entries in the list of touchstone files for the current configura-
tion.
Suffix:
<si>
.
1..n
irrelevant
<sli> irrelevant
Return values:
<Size> integer
Range: 1 to 15
*RST: 1
Example:
SENS:CORR:FRES:USER:SLIS:SIZE?
Usage: Query only
Configuring the R&S FSW
