R&S FSW Series User Manual

Remote Commands
R&S
®
FSW
1335User Manual 1173.9411.02 ─ 43
In many cases the selection of commands supported by the R&S FSW is sufficient to
run an existing GPIB program without adaptation.
After the introduction, this section includes the following topics:
● Command Set of Models 8560E, 8561E, 8562E, 8563E, 8564E, 8565E, 8566A/B,
8568A/B, 8591E, 8594E, 71100C, 71200C, and 71209A................................... 1335
● Special Features of the Syntax Parsing Algorithms for 8566A and 8568A Models
............................................................................................................................ 1359
● Special Behavior of Commands..........................................................................1360
● Model-Dependent Default Settings..................................................................... 1361
● Data Output Formats...........................................................................................1362
● Trace Data Output Formats................................................................................ 1362
● Trace Data Input Formats................................................................................... 1362
● GPIB Status Reporting........................................................................................1362
14.13.2.1 Command Set of Models 8560E, 8561E, 8562E, 8563E, 8564E, 8565E, 8566A/B,
8568A/B, 8591E, 8594E, 71100C, 71200C, and 71209A
As with the original units, the R&S FSW includes the command set of the A models in
the command set of the B models.
The HP model 8591E is compatible to HP model 8594E, the HP models 71100C,
71200C, and 71209A are compatible to HP models 8566A/B.
Command Supported subset Function Corresp. HP-
Models
Status
A1 A1 Clear/Write A HP 8566A/
HP 8568A
available
A2 A2 Max Hold A HP 8566A/
HP 8568A
available
A3 A3 View A HP 8566A/
HP 8568A
available
A4 A4 Blank A HP 8566A/
HP 8568A
available
ABORT
1)
ABORT Stop previous function HP 856xE/
HP 8566B/HP
8568B/HP
8594E
available
ADD Add HP 8566B/
HP 8568B/
HP 8594E
available
Emulating Other Instruments' Commands
