Common Analysis and Display Functions
R&S
®
FSW
570User Manual 1173.9411.02 ─ 43
For details on the file format see Chapter 9.4.2.4, "Reference: Limit Line File Format",
on page 574.
The limit line can be imported again later by the R&S FSW for use in other measure-
ments.
Remote command:
MMEMory:STORe<n>:LIMit on page 1223
File Explorer ← Export
Opens the Microsoft Windows File Explorer.
Remote command:
not supported
9.4.2.3 How to Define Limit Lines
Access: "Overview" > "Analysis" > "Lines" > "Limit Lines"
or: [LINES] > "Line Config" > "Limit Lines"
Limit lines for spurious and SEM measurements
Note that for spurious and SEM measurements, special limit lines can be defined for
each frequency range, see Chapter 7.6.4.2, "Limit Lines in SEM Measurements",
on page 242 and Chapter 7.7.3.2, "Limit Lines in Spurious Measurements",
on page 283. It is strongly recommended that you define limits only via the "Sweep
List" dialog for these measurements, not using the [Lines] key.
Any changes to the special limit lines are automatically overwritten when the sweep list
settings are changed.
The following tasks are described here:
"How to find compatible limit lines" on page 570
"How to activate and deactivate a limit check" on page 571
"How to edit existing limit lines" on page 571
"How to copy an existing limit line" on page 571
"How to delete an existing limit line" on page 571
"How to configure a new limit line" on page 572
"How to move the limit line vertically or horizontally" on page 573
How to find compatible limit lines
In the "Line Config" dialog box, select the "View Filter" option: "Show Compatible".
All stored limit lines with the file extension .LIN in the limits subfolder of the
main installation folder of the instrument that are compatible to the current mea-
surement settings are displayed in the overview.
Display and Limit Lines
