R&S FSW Series User Manual

Remote Commands
R&S
®
FSW
839User Manual 1173.9411.02 ─ 43
CPOWer
Channel power measurements.
Returns the channel power. The unit of the return values
depends on the scaling of the y-axis:
• logarithmic scaling returns the power in the current unit
• linear scaling returns the power in W
For SEM measurements, the return value is the channel power
of the reference range (in the specified sub block).
PPOWer
Peak power measurements.
Returns the peak power. The unit of the return values depends
on the scaling of the y-axis:
• logarithmic scaling returns the power in the current unit
• linear scaling returns the power in W
For SEM measurements, the return value is the peak power of
the reference range (in the specified sub block).
Note that this result is only available if the power reference type
is set to peak power (see [SENSe:]ESPectrum<sb>:RTYPe
on page 937).
OBANdwidth | OBWidth
Occupied bandwidth.
Returns the occupied bandwidth in Hz.
COBandwidth | COBWidth
<Centroid frequency>,<Frequency offset>
See Chapter 7.4.2, "OBW Results", on page 214
Manual operation:
See "C/N" on page 211
See "C/N0" on page 211
CALCulate<n>:MARKer<m>:FUNCtion:POWer<sb>:SELect <MeasType>
This command selects a power measurement and turns the measurement on.
Suffix:
<n>
.
Window
<m> Marker
<sb> irrelevant
Parameters:
<MeasType> ACPower | MCACpower
Adjacent channel leakage ratio (ACLR), also known as adjacent
channel power or multicarrier adjacent channel.
The R&S FSW performs the measurement on the trace selected
with [SENSe:]POWer:TRACe.
CPOWer
Channel power measurement with a single carrier.
The R&S FSW performs the measurement on the trace selected
with [SENSe:]POWer:TRACe.
Configuring and Performing Measurements
