R&S FSW Series - Page 840

Remote Commands
R&S
®
FSW
840User Manual 1173.9411.02 ─ 43
OBANdwidth | OBWidth
Occupied bandwidth measurement.
The R&S FSW performs the measurement on the trace that
marker 1 is positioned on.
CN
Carrier-to-noise ratio measurement.
CN0
Carrier-to-noise ratio measurement referenced to 1 Hz band-
width
Manual operation: See "C/N" on page 211
See "C/N0" on page 211
CALCulate<n>:MARKer<m>:FUNCtion:POWer<sb>[:STATe]
<State>
This command turns a power measurement on and off.
Suffix:
<n>
.
irrelevant
<m> irrelevant
<sb> irrelevant
Parameters:
<State> ON | OFF | 1 | 0
ON | 1
The power measurement selected with CALCulate<n>:
MARKer<m>:FUNCtion:POWer<sb>:SELect is activated.
OFF | 0
A standard frequency sweep is activated.
*RST: 0
Manual operation: See "C/N" on page 211
See "C/N0" on page 211
[SENSe:]POWer:ACHannel:PRESet <Measurement>
This command determines the ideal span, bandwidths and detector for the current
power measurement.
To get a valid result, you have to perform a complete measurement with synchroniza-
tion to the end of the measurement before reading out the result. This is only possible
for single sweep mode.
See also INITiate<n>:CONTinuous on page 835.
Parameters:
<Measurement> ACPower | MCACpower
ACLR measurement
CPOWer
channel power measurement
Configuring and Performing Measurements
