R&S FSW Series User Manual

Remote Commands
R&S
®
FSW
867User Manual 1173.9411.02 ─ 43
[SENSe:]POWer:ACHannel:AGCHannels <State>
This command activates or deactivates gap channels in an MSR signal.
For more information see Chapter 7.2.3.4, "Measurement on Multi-Standard Radio
(MSR) Signals", on page 162.
Parameters:
<State> ON | OFF | 1 | 0
ON | 1
The gap channels are displayed and channel power results are
calculated and displayed in the Result Summary.
OFF | 0
The gap channels are not displayed in the diagram and channel
power results are not calculated nor displayed in the Result
Summary.
*RST: 1
Manual operation: See "Activate Gaps" on page 190
[SENSe:]POWer:ACHannel:GAP<gap>:MODE <Mode>
Defines how gap channels are configured.
Suffix:
<gap>
.
1 | 2
irrelevant
Parameters:
<Mode> AUTO | MANual
AUTO
In "Auto" mode, upper and lower gap channels are configured
identically, so only two channels need to be configured (gap 1,
gap 2). Gap channels are configured identically for all gaps, if
more than two sub blocks are defined. Depending on the
defined minimum gap size, the actual number of evaluated gap
channels is determined automatically.
See also [SENSe:]POWer:ACHannel:GAP<gap>[:AUTO]:
MSIZe on page 872.
MANual
In "Manual" mode, up to four channels can be configured individ-
ually for each gap. All configured gap channels are always eval-
uated, regardless of the gap size.
See also [SENSe:]POWer:ACHannel:GAP<gap>:MANual:
CHANnel:COUNt:LOWer on page 884 and [SENSe:
]POWer:ACHannel:GAP<gap>:MANual:CHANnel:COUNt:
UPPer on page 885.
*RST:
AUTO
Example:
SENS:POW:ACH:GAP:MODE MAN
Configuring and Performing Measurements
