R&S FSW Series User Manual

Remote Commands
R&S
®
FSW
868User Manual 1173.9411.02 ─ 43
Example: See "Example: Configuring and Performing an Asymmetrical
MSR ACLR Measurement" on page 895
Manual operation: See "Gap Mode" on page 190
Automatic (Symmetrical) Configuration
The following commands are only available for symmetrical (automatic) configuration
of gap channels (see [SENSe:]POWer:ACHannel:GAP<gap>:MODE on page 867).
CALCulate<n>:LIMit<li>:ACPower:GAP<gap>[:AUTO]:ABSolute........................................ 868
CALCulate<n>:LIMit<li>:ACPower:GAP<gap>[:AUTO]:ABSolute:STATe.............................. 868
CALCulate<n>:LIMit<li>:ACPower:GAP<gap>[:AUTO]:ACLR[:RELative]............................. 869
CALCulate<n>:LIMit<li>:ACPower:GAP<gap>[:AUTO]:ACLR[:RELative]:STATe................... 869
CALCulate<n>:LIMit<li>:ACPower:GAP<gap>[:AUTO][:CACLr][:RELative].......................... 870
CALCulate<n>:LIMit<li>:ACPower:GAP<gap>[:AUTO][:CACLr][:RELative]:STATe................ 870
[SENSe:]POWer:ACHannel:BWIDth:GAP<gap>[:AUTO].................................................... 871
[SENSe:]POWer:ACHannel:BANDwidth:GAP<gap>[:AUTO]...............................................871
[SENSe:]POWer:ACHannel:FILTer:ALPHa:GAP<gap>[:AUTO]........................................... 871
[SENSe:]POWer:ACHannel:FILTer[:STATe]:GAP<gap>[:AUTO].......................................... 871
[SENSe:]POWer:ACHannel:GAP<gap>[:AUTO]:MSIZe......................................................872
[SENSe:]POWer:ACHannel:SPACing:GAP<gap>[:AUTO].................................................. 872
CALCulate<n>:LIMit<li>:ACPower:GAP<gap>[:AUTO]:ABSolute <Limit>[,
<Reserved>]
This command defines the absolute limit of the specified gap (CACLR) channel.
If you define both an absolute limit and a relative limit, the R&S FSW uses the lower
value for the limit check.
Suffix:
<n>
.
irrelevant
<li> irrelevant
<gap> 1 | 2
Gap (CACLR) channel number
Parameters:
<Limit> Defines the absolute limit of the specified gap channel.
Default unit: dBm
<Reserved> Ignored.
Example:
CALC:LIM:ACP:GAP2:ABS 44.2dBm
CALCulate<n>:LIMit<li>:ACPower:GAP<gap>[:AUTO]:ABSolute:STATe <State>
This command turns the absolute limit check for the specified gap (CACLR) channel on
and off.
You have to activate the general ACLR limit check before using this command with
CALCulate<n>:LIMit<li>:ACPower[:STATe].
Configuring and Performing Measurements
